Here's what the final breadboarded circuit looks like:
Sounds good - now it's just a matter of transferring it from the breadboard to a regular circuit board, and finding a box to house it.
The two small holes at the center are for the photoresistors, which are held in place by plastic soda straws.
Then I put together a second Hex Schmitt Trigger oscillator, the output of which is connected to a single LED. The LED blinks at a variable rate controlled by two potentiometers.
Next I inserted an LED into one of the photoresistor holes in the Drone Box. The LED was then attached to the second oscillator output with clip leads and held in place with electrical tape.
So, what does it sound like? The first video below shows the Drone Box with the pitch of the photoresistors manipulated by a flashlight. The second video shows the box with the oscillation regulated by the blinking LED.
